Home ElecFreaks Octopus 0.36'' Segment LED Brick
ElecFreaks

Octopus 0.36'' Segment LED Brick

EF04056

Elmwood Electronics has stopped accepting orders. This product might be available at PiShop.ca. Please check this blog post about our recent team merger.

Continue Shopping or View Cart
OCTOPUS 036A Segmentric is an easy-designed type of digital tube electronic building block with 0.36 inches common anode display, used for simple numbers or numbers with decimal point display.

Specification:

Power supply: 3.3 V/5V

Support ISO/IEC: 14443 A/MIFARE

Support: mifare1 S50/mifare1 S70/mifare UltraLigh/mifare Pro/mifare Desfire

Operating distance in Read/Write mode: up to 40 mm

FIFO buffer handles: 64 byte send and receive

SPI: interface

Working current: 13~26mA

Idle current: 10—13mA

Working temperature: -25 ~ 85

Size: 71.00mm×40.90mm

Resources:

Datasheet

Schematics

SPEC

User_Guide

Source Code

Please visit the ElecFreaks wiki page for more info about this product. It will be appreciated if you can help us improve the documents, add more demo code or tutorials.


Collections: ElecFreaks

Type: Octopus Electric Bricks
